Technical Specifications - CAN to Analogue Output Module

VBOX Automotive

VBOX Motorsport

LabSat

VBOX Positioning

General Knowledge Bases

Specifications #

Channels	Analogue: 4 Digital: 7
Signal Range	Analogue Voltage: 0 to + 10 V DC Voltage Accuracy: ± 0.1% Digital: 0 V/ + 12 V DC

Analogue Voltage	12 bit, 2.44 mV per bit
Timer Compare	16 bit

12 V DC (± 10)

Type	CAN 2.0 A or CAN 2.0 B compatible
Baud Rates	250 kbit/s, 500 kbit/s, 1 Mbit/s

Operating Temperature	0 to 60 °C
IP Rating	IP50
