| Velocity | |
|---|---|
| Accuracy | 0.2 Km/h (averaged over 4 samples) |
| Units | Km/h or Mph |
| Maximum update rate | 10 Hz |
| Maximum velocity/ Minimum velocity | 1000 Mph/0.1 Km/h |
| Resolution | 0.01 Km/h |
| Latency | >160ms |
| Distance | |
|---|---|
| Accuracy | 0.05% (<50cm per Km) |
| Units | Metres / Feet |
| Maximum update rate | 10 Hz |
| Resolution | 1cm |
| Absolute Positioning | |
|---|---|
| Accuracy | 5m 95% CEP** |
| Height accuracy | 10 Metres 95% CEP** |
| Maximum update rate | 10 Hz |
| Resolution | 1 cm |
| Heading | |
|---|---|
| Resolution | 0.01° |
| Accuracy | 0.2° |
| Time | |
|---|---|
| Resolution | 0.01 s |
| Accuracy | 0.1 s (0.01s for results scanned in VBOXTools) |
| Acceleration | |
|---|---|
| Accuracy | 1% |
| Maximum | 4 G |
| Resolution | 0.01 G |
| Maximum update rate | 10 Hz |
| Inputs | |
|---|---|
| CAN Bus | CAN connection for Racelogic modules only |
| VCI CAN Input | Allows the user to log incoming CAN data from other systems |
| CAN Bus Outputs | |
|---|---|
| Bit rate | 125, 250, 500kbit/s & 1Mbit/s selectable baud rate |
| Identifier type | Standard 11bit and Extended 29bit 2.0A |
| Data available | Satellites, UTC time, Latitude, Longitude, Speed, Heading, Altitude, Vertical velocity, Longitudinal & Lateral acceleration, Distance since reset |
| Power | |
|---|---|
| Input Voltage range | 6-30V DC |
| Current | Typically 70mA |
| Environmental and physical | |
|---|---|
| Weight | Approx 275 grams |
| Size | 105mm x 85 x 30mm |
| Operating temperature | -10˚C to +60˚C |
| Storage temperature | -40˚C to +85˚C |
** CEP = Circle of Error Probable 95% CEP (Circle Error Probable) means 95% of the time the position readings will fall within a circle of the stated radius.
